single-phase motors
single-phase motors
6 Poli - 1000rpm
Squirrel cage rotor - Totally enclosed fan cooled IP55 - Ins.cl.F - 230V 50Hz
| TIPO MOTORE MOTOR TYPE |
POTENZA NOMINALE RATED OUTPUT |
velocità speed |
rendimento efficency |
fattore di potenza power factor |
Corrente corrent 230V |
corrente avviamento current for d.o.l. starting |
Condens. capacitor |
coppia torque |
momento d'inserzia moment of inertia |
peso (b3) weight b3 |
|
|---|---|---|---|---|---|---|---|---|---|---|---|
| RNM | Kw | rpm | % | COSφ | A | IS/IN | μF | Nm | Cs/Cn | Kgm² | Kg |
| RNM 71a6 | 0,11 | 865 | 55 | 0,97 | 1,20 | 2,00 | 6,3 | 1,21 | 0,85 | 0,0006 | 7,0 |
| RNM 71b6 | 0,15 | 870 | 56 | 0,96 | 1,70 | 2,00 | 10,0 | 1,65 | 0,85 | 0,0009 | 8,0 |
| RNM 80a6 | 0,25 | 880 | 58 | 0,97 | 2,40 | 2,00 | 14,0 | 2,71 | 0,90 | 0,0018 | 11,0 |
| RNM 80b6 | 0,37 | 885 | 58 | 0,96 | 3,50 | 2,00 | 16,0 | 3,99 | 0,90 | 0,0021 | 11,5 |
| RNM 80c6 | 0,55 | 880 | 55 | 0,95 | 4,40 | 2,00 | 20,0 | 5,96 | 0,90 | 0,0025 | 12,0 |
| RNM 90Sa6 | 0,55 | 870 | 60 | 0,96 | 4,60 | 2,00 | 25,0 | 6,03 | 0,80 | 0,0028 | 15,0 |
| RNM 90La6 | 0,75 | 890 | 65 | 0,96 | 6,00 | 2,10 | 30,0 | 8,04 | 0,75 | 0,0035 | 17,0 |
| RNM 100a6 | 1,10 | 895 | 65 | 0,96 | 8,20 | 2,50 | 50,0 | 11,7 | 0,65 | 0,0058 | 21,0 |
| RNM 100b6 | 1,35 | 895 | 68 | 0,97 | 9,50 | 2,55 | 55,0 | 14,4 | 0,60 | 0,0071 | 23,0 |
